PAD-LOC MARITIME CARPET SUPPORT®
PAD-LOC MARITIME CARPET SUPPORT® is designed for marine use and offers features and benefits to help protect and extend the life of carpet. This underlayment also complies with all applicable regulations and requirements, and is one of the most energy-efficient options on the market.
Benefits
- Dramatically reduces carpet wear and extends appearance retention
- Fuel Saver – 65% less weight than comparable products
- Low-profile design provides excellent door clearance
- Noise Reduction – Rebond cushion is excellent for reducing airborne and impact noise transmission
- Helps reduce body stress and fatigue
- Fresh Dimension® antimicrobial treatment inhibits the growth of mold, mildew, and odor-causing bacteria
- Recyclable at the end of its useful life
Certifications
- Complies with SOLAS and U.S. Coast Guard requirements
- Wheel Mark-certified as defined by EU directive on marine equipment
- Passes International Maritime Organization fire codes
- Green Label Plus-certified for indoor air quality
- ISO 9000 Compliant : LP9000 Certified
| Specification Name | Standard | Metric |
|---|---|---|
| Item No. | BZ0465 | BZ0465 |
| Composition | Rebond Foam | Rebond Foam |
| Density | 11.5 lbs/ft.³ | 184 kg/m³ |
| Weight | 26 oz/yd² | 881.5 g/m² |
| Thickness | 0.180″ (+/- 0.020″) | 4.6 mm (+/- 0.508 mm) |
| Dimensions | 6′ x 60′ | 1.83 m x 18.3 m |
| Roll Size | 360 ft² | 33.4 m² |
| Compression Force Deflection @ 25% / 65% deflection | 3.2 psi/18.6 psi | 22 kPa/128.2 kPa |
| Compression Set (Max) | 14.4% | 14.4% |
| Tensile Strength | 28 psi | 193 kPa |
| Impact Sound Transmission (ASTM E492-77) | IIC 71 | IIC 71 |
| Commercial Traffic Class | Heavy | Heavy |
| IMO FTPC Part 5, Res. A.653 (16) | Passes | Passes |
| IMO FTPC Part 2, ISO 5659-2:2006 | Passes | Passes |
| Wheel Mark Certificate | LRD No. 0525 | LRD No. 0525 |
| Lloyd’s Register Certificate of Fire Approval | SAS F090321 | SAS F090321 |
| Antimicrobial Treated | Fresh Dimension® | Fresh Dimension® |
| CRI Indoor Air Quality Testing | Green Label Plus | Green Label Plus |
| Assigned U.S. Coast Guard Module B No. | 164.117/EC0038 | 164.117/EC0038 |
| Warranty | Commercial | Commercial |
